C ONFIGURING THE S WITCH
3-122
CLI – The following example configures LACP parameters for ports 1-4.
Ports 1-4 are used as active members of the LAG.
Displaying LACP Port Counters
You can display statistics for LACP protocol messages.
Console(config)#interface ethernet 1/1 4-156
Console(config-if)#lacp actor system-priority 3 4-179
Console(config-if)#lacp actor admin-key 120 4-180
Console(config-if)#lacp actor port-priority 128 4-181
Console(config-if)#exit
.
.
.
Console(config)#interface ethernet 1/4
Console(config-if)#lacp actor system-priority 3
Console(config-if)#lacp actor admin-key 120
Console(config-if)#lacp actor port-priority 512
Console(config-if)#end
Console#show lacp sysid 4-182
Port Channel System Priority System MAC Address
-------------------------------------------------------------------------
1 3 00-12-CF-31-31-31
2 32768 00-12-CF-31-31-31
3 32768 00-12-CF-31-31-31
4 32768 00-12-CF-31-31-31
Console#show lacp 1 internal 4-182
Port channel : 1
-------------------------------------------------------------------------
Oper Key : 120
Admin Key : 0
Eth 1/1
-------------------------------------------------------------------------
LACPDUs Internal: 30 sec
LACP System Priority: 3
LACP Port Priority: 128
Admin Key: 120
Oper Key: 120
Admin State : defaulted, aggregation, long timeout, LACP-activity
Oper State: distributing, collecting, synchronization,
aggregation, long timeout, LACP-activity
.
.
.
Table 3-8. LACP Port Counters
Field Description
LACPDUs Sent Number of valid LACPDUs transmitted from this channel
group.
LACPDUs Received Number of valid LACPDUs received on this channel group.
