P
RIORITY
C
OMMANDS
4-251
Default Setting
Weights 1, 2, 4, 8 are assigned to queues 0-3 respectively.
Command Mode
Global Configuration
Command Usage
WRR controls bandwidth sharing at the egress port by defining
scheduling weights.
Example
This example shows how to assign WRR weights to priority queues 0 - 2:
Related Commands
show queue bandwidth (4-253)
queue cos-map
This command assigns class of service (CoS) values to the priority queues
(i.e., hardware output queues 0 - 3). Use the no form set the CoS map to
the default values.
Syntax
queue cos-map queue_id [cos1 ... cosn]
no queue cos-map
- queue_id - The ID of the priority queue.
Ranges are 0 to 3, where 3 is the highest priority queue.
- cos1 .. cosn - The CoS values that are mapped to the queue ID. It is a
space-separated list of numbers. The CoS value is a number from 0
to 7, where 7 is the highest priority.
Default Setting
Console(config)#queue bandwidth 6 9 12
Console(config)#
