B
ASIC
C
ONFIGURATION
3-19
Figure 3-5. Bridge Extension Configuration
CLI – Enter the following command.
Setting the Switch’s IP Address
This section describes how to configure an IP interface for management
access over the network. The IP address for the stack is obtained via
DHCP by default. To manually configure an address, you need to change
the switch’s default settings (IP address 192.168.1.1 and netmask
255.255.255.0) to values that are compatible with your network. You may
also need to a establish a default gateway between the stack and
management stations that exist on another network segment.
Console#show bridge-ext 4-219
Max support VLAN numbers: 256
Max support VLAN ID: 4094
Extended multicast filtering services: No
Static entry individual port: Yes
VLAN learning: SVL
Configurable PVID tagging: Yes
Local VLAN capable: No
Traffic classes: Enabled
Global GVRP status: Disabled
GMRP: Disabled
Console#
