C
ONFIGURING
THE
S
WITCH
3-260
CLI – This example first enables clustering on the switch, sets the switch
as the cluster Commander, and then configures the cluster IP pool.
Cluster Member Configuration
Adds Candidate switches to the cluster as Members.
Command Attributes
• Member ID – Specify a Member ID number for the selected
Candidate switch. (Range: 1-36)
• MAC Address – Select a discoverd switch MAC address from the
Candidate Table, or enter a specific MAC address of a known switch.
Web – Click Cluster, Member Configuration.
Figure 3-118. Cluster Member Configuration
Console(config)#cluster 4-310
Console(config)#cluster commander 4-311
Console(config)#cluster ip-pool 10.2.3.4 4-312
Console(config)#
