M
ULTICAST
VLAN R
EGISTRATION
3-241
• Immediate Leave – Shows if immediate leave is enabled or disabled.
• Trunk Member
13
– Shows if port is a trunk member.
Web – Click MVR, Port or Trunk Information.
Figure 3-105. MVR Port Information
CLI – This example shows information about interfaces attached to the
MVR VLAN.
Displaying Port Members of Multicast Groups
You can display the multicast groups assigned to the MVR VLAN either
through IGMP snooping or static configuration.
Field Attributes
• Group IP – Multicast groups assigned to the MVR VLAN.
13.
Port Information only.
Console#show mvr interface 4-287
Port Type Status Immediate Leave
------- -------- ------------- ---------------
eth1/1 SOURCE ACTIVE/UP Disable
eth1/2 RECEIVER ACTIVE/UP Disable
Console#
