B
ASIC
C
ONFIGURATION
3-21
Manual Configuration
Web – Click System, IP Configuration. Select the VLAN through which
the management station is attached, set the IP Address Mode to “Static,”
enter the IP address, subnet mask and gateway, then click Apply.
Figure 3-6. Manual IP Configuration
CLI – Specify the management interface, IP address and default gateway.
Console#config
Console(config)#interface vlan 1 4-156
Console(config-if)#ip address 192.168.1.1 255.255.255.0 4-290
Console(config-if)#exit
Console(config)#ip default-gateway 0.0.0.0 4-292
Console(config)#
