C
ONFIGURING
THE
S
WITCH
3-198
Web – Click VLAN, Private VLAN, Association. Select the required
primary VLAN from the scroll-down box, highlight one or more
community VLANs in the Non-Association list box, and click Add to
associate these entries with the selected primary VLAN. (A community
VLAN can only be associated with one primary VLAN.)
Figure 3-83. Private VLAN Association
CLI – This example associates community VLANs 6 and 7 with primary
VLAN 5.
Displaying Private VLAN Interface Information
Use the Private VLAN Port Information and Private VLAN Trunk
Information menus to display the interfaces associated with private
VLANs.
Command Attributes
• Port/Trunk – The switch interface.
• PVLAN Port Type – Displays private VLAN port types.
- Normal – The port is not configured in a private VLAN.
Console(config)#vlan database 4-223
Console(config-vlan)#private-vlan 5 association 6 4-237
Console(config-vlan)#private-vlan 5 association 7 4-237
Console(config)#
