C
ONFIGURING
THE
S
WITCH
3-200
CLI – This example shows the switch configured with primary VLAN 5
and community VLAN 6. Port 3 has been configured as a promiscuous
port and mapped to VLAN 5, while ports 4 and 5 have been configured as
host ports and associated with VLAN 6. This means that traffic for port 4
and 5 can only pass through port 3.
Configuring Private VLAN Interfaces
Use the Private VLAN Port Configuration and Private VLAN Trunk
Configuration menus to set the private VLAN interface type, and assign
the interfaces to a private VLAN.
Command Attributes
• Port/Trunk – The switch interface.
• PVLAN Port Type – Sets the private VLAN port types.
- Normal – The port is not assigned to a private VLAN.
- Host – The port is a community port or an isolated port. A
community port can communicate with other ports in its own
community VLAN and with designated promiscuous port(s). An
isolated port can only communicate with the single designated
promiscuous port in the isolated VLAN; it cannot communicate
with any other host ports.
- Promiscuous – A promiscuous port can communicate with all
interfaces within a private VLAN.
• Primary VLAN – Conveys traffic between promiscuous ports, and
between promiscuous ports and community ports within the
associated secondary VLANs. If PVLAN type is “Promiscuous,” then
specify the associated primary VLAN.
Console#show vlan private-vlan 4-241
Primary Secondary Type Interfaces
-------- ----------- ---------- ------------------------------
5 primary Eth1/ 3
5 6 community Eth1/ 4 Eth1/ 5
Console#
