C
ONFIGURING
THE
S
WITCH
3-206
Figure 3-88. Port Priority Configuration
CLI – This example assigns a default priority of 5 to port 3.
Mapping CoS Values to Egress Queues
This switch processes Class of Service (CoS) priority tagged traffic by
using four priority queues for each port, with service schedules based on
strict or Weighted Round Robin (WRR). Up to eight separate traffic
Console(config)#interface ethernet 1/3 4-156
Console(config-if)#switchport priority default 5 4-249
Console(config-if)#end
Console#show interfaces switchport ethernet 1/3 4-168
Information of Eth 1/3
Broadcast threshold: Enabled, 500 packets/second
LACP status: Disabled
Ingress rate limit: enable, K bits per second: 25
VLAN membership mode: Hybrid
Ingress rule: Enabled
Acceptable frame type: All frames
Native VLAN: 1
Priority for untagged traffic: 5
GVRP status: Disabled
Allowed VLAN: 1(u),
Forbidden VLAN:
Private-VLAN mode: NONE
Private-VLAN host-association: NONE
Private-VLAN mapping: NONE
Console#
