C
ONFIGURING
THE
S
WITCH
3-208
Web – Click Priority, Traffic Classes. The current mapping of CoS values
to output queues is displayed. Assign priorities to the traffic classes (i.e.,
output queues), then click Apply.
Figure 3-89. Traffic Classes
CLI – The following example shows how to change the CoS assignments.
* Mapping specific values for CoS priorities is implemented as an interface
configuration command, but any changes will apply to the all interfaces on the
switch.
Enabling CoS
Enable or disable Class of Service (CoS). Command Attributes
• Traffic Classes – Click to enable Class of Service. (Default: Enabled)
Console(config)#interface ethernet 1/1 4-156
Console(config-if)#queue cos-map 0 0 4-251
Console(config-if)#queue cos-map 1 1
Console(config-if)#queue cos-map 2 2
Console(config-if)#end
Console#show queue cos-map ethernet 1/1 4-253
Information of Eth 1/1
CoS Value: 0 1 2 3 4 5 6 7
Priority Queue: 0 1 2 1 2 2 3 3
Console#
