C
ONFIGURING
THE
S
WITCH
3-226
Figure 3-97. Service Policy Settings
CLI - This example applies a service policy to an ingress interface.
Multicast Filtering
Multicasting is used to support real-time
applications such as videoconferencing
or streaming audio. A multicast server
does not have to establish a separate
connection with each client. It merely
broadcasts its service to the network, and
any hosts that want to receive the
multicast register with their local
multicast switch/router. Although this
approach reduces the network overhead
required by a multicast server, the
broadcast traffic must be carefully
Console(config)#interface ethernet 1/5 4-120
Console(config-if)#service-policy input rd_policy#3 4-203
Console(config-if)#
Unicast
Flow
Multicast
Flow
To Next Page
