B
ASIC
C
ONFIGURATION
3-15
CLI – Specify the hostname, location and contact information.
Displaying Switch Hardware/Software Versions
Use the Switch Information page to display hardware/firmware version
numbers for
the main board and management software, as well as the
power status of the system.
Field Attributes
Main Board
• Serial Number – The serial number of the switch.
• Number of Ports – Number of built-in RJ-45 ports.
• Hardware Version – Hardware version of the main board.
• Internal Power Status – Displays the status of the internal power
supply.
Console(config)#hostname R&D 5 4-34
Console(config)#snmp-server location WC 9 4-141
Console(config)#snmp-server contact Ted 4-140
Console(config)#exit
Console#show system 4-84
System description : 24 10/100 ports and 4 gigabit ports with PoE switch
System OID string : 1.3.6.1.4.1.202.20.65
System information
System Up time : 0 days, 0 hours, 14 minutes, and 32.93 seconds
System Name : R&D 5
System Location : WC 9
System Contact : Ted
MAC address : 00-00-35-28-10-03
Web server : enabled
Web server port : 80
Web secure server : enabled
Web secure server port : 443
Telnet server : enable
Telnet port : 23
Jumbo Frame : Disabled
POST result
UART Loopback Test ........... PASS
DRAM Test .................... PASS
Timer Test ................... PASS
PCI Device 1 Test ............ PASS
I2C Bus Initialization ....... PASS
Switch Int Loopback Test ..... PASS
Fan Speed Test ............... PASS
Done All Pass.
Console#
