C
ONFIGURING
THE
S
WITCH
3-234
Web – Click IGMP Snooping, Static Multicast Router Port Configuration.
Specify the interfaces attached to a multicast router, indicate the VLAN
which will forward all the corresponding multicast traffic, and then click
Add. After you have finished adding interfaces to the list, click Apply.
Figure 3-101. Static Multicast Router Port Configuration
CLI – This example configures port 11 as a multicast router port within
VLAN 1.
Displaying Port Members of Multicast Services
You can display the port members associated with a specified VLAN and
multicast service.
Command Attributes
• VLAN ID – Selects the VLAN for which to display port members.
• Multicast IP Address – The IP address for a specific multicast
service.
Console(config)#ip igmp snooping vlan 1 mrouter ethernet 1/11 4-279
Console(config)#exit
Console#show ip igmp snooping mrouter vlan 1 4-280
VLAN M'cast Router Port Type
---- ------------------ -------
1 Eth 1/11 Static
Console#
