S
WITCH
C
LUSTERING
3-261
CLI – This example creates a new cluster Member by specifying the
Candidate switch MAC address and setting a Member ID.
Cluster Member Information
Displays current cluster Member switch information.
Command Attributes
• Member ID – The ID number of the Member switch. (Range: 1-36)
• Role – Indicates the current status of the switch in the cluster.
• IP Address – The internal cluster IP address assigned to the Member
switch.
• MAC Address – The MAC address of the Member switch.
• Description – The system description string of the Member switch.
Web – Click Cluster, Member Information.
Figure 3-119. Cluster Member Information
Console(config)#cluster member mac-address 00-12-34-56-78-9a id 5 4-313
Console(config)#
