P
ORT
C
ONFIGURATION
3-125
Web – Click Port, LACP, Port Internal Information. Select a port channel
to display the corresponding information.
LACP Port Priority LACP port priority assigned to this interface within the channel
group.
Admin State,
Oper State
Administrative or operational values of the actor’s state parameters:
• Expired – The actor’s receive machine is in the expired state;
• Defaulted – The actor’s receive machine is using defaulted
operational partner information, administratively configured for
the partner.
• Distributing – If false, distribution of outgoing frames on this link
is disabled; i.e., distribution is currently disabled and is not expected
to be enabled in the absence of administrative changes or changes
in received protocol information.
• Collecting – Collection of incoming frames on this link is enabled;
i.e., collection is currently enabled and is not expected to be
disabled in the absence of administrative changes or changes in
received protocol information.
• Synchronization – The System considers this link to be IN_SYNC;
i.e., it has been allocated to the correct Link Aggregation Group,
the group has been associated with a compatible Aggregator, and
the identity of the Link Aggregation Group is consistent with the
System ID and operational Key information transmitted.
• Aggregation – The system considers this link to be aggregatable;
i.e., a potential candidate for aggregation.
• Long timeout – Periodic transmission of LACPDUs uses a slow
transmission rate.
• LACP-Activity – Activity control value with regard to this link.
(0: Passive; 1: Active)
Table 3-9. LACP Internal Configuration Information (Continued)
Field Description
