C OMMAND L INE I NTERFACE
4-132
-tagged-eth2 – Tagged Ethernet II packets.
-untagged-eth2 – Untagged Ethernet II packets.
-tagged-802.3 – Tagged Ethernet 802.3 packets.
-untagged-802.3 – Untagged Ethernet 802.3 packets.
-any – Any MAC source or destination address.
-host – A specific MAC address.
-source – Source MAC address.
-destination – Destination MAC address range with bitmask.
-address-
bitmask
16
– Bitmask for MAC address (in hexidecimal format).
-vid – VLAN ID. (Range: 1-4093)
-
vid-bitmask
16
– VLAN bitmask. (Range: 1-4093)
-protocol – A specific Ethernet protocol number. (Range: 600-fff hex.)
- protocol - bitmask
16
– Protocol bitmask. ( Range: 600-fff hex. )
Default Setting
None
Command Mode
MAC ACL
Command Usage
•New rules are added to the end of the list.
•The ethertype option can only be used to filter Ethernet II formatted
packets.
•A detailed listing of Ethernet protocol types can be found in RFC 1060.
A few of the more common types include the following:
-0800 - IP
-0806 - ARP
-8137 - IPX
Example
This rule permits packets from any source MAC address to the destination
address 00-e0-29-94-34-de where the Ethernet type is 0800.
16. For all bitmasks, “1” means care and “0” means ignore.
Console(config-mac-acl)#permit any host 00-e0-29-94-34-de ethertype
0800
Console(config-mac-acl)#
