Topcon Pocket-3D - Stake-Out Next Point; Sideslope Options

Stake-out
P/N 7010-0628
4-53
Stake-out Next Point
To activate the Stake-out next point menu, first stake out points on a
side slope (See
“Side Slopes” on page 4-41).
To stake out the next point, tap SurveyStake-outStake-out next
point (
Figure 4-79). This menu option is only available if “Regular
station/transition” is selected on the Stake-out dialog box when
staking out points on a side slope. See
“Side Slopes” on 
page 4-41 for more information.
Figure 4-79. SurveyStake-outStake-out NextPoint
Sideslope Options
To view or change options for slope or cross-slope stake-out
measurements only, tap Survey
Stake-outSideslope Options
(
Figure 4-80).
Figure 4-80. Slope Options for Side/Cross-Section Slopes
