Topcon Pocket-3D - Equipment Configuration Files

Equipment Configuration Files
P/N 7010-0628
2-13
Equipment Configuration Files
Equipment configuration files contain information on the specific
machine, GPS+ receiver, prism, radio, etc., for the job application and
setup. Pocket-3D uses this information to accurately portray jobsite
information on the main screen.
The following sections provide example equipment configurations:
one for a range-pole with a HiPer® Lite receiver, one for a motor
grader machine rover with mmGPS, one for a motor grader with an
LS-2000 receiver, and another one for a prism/total station setup.
An equipment configuration file can be created in one of two ways:
• Import the file created at the System Five-3D Control Box
through the compact flash card using the Copy button. See
“Project” on page 3-2 for details.
• Create the file manually.
Sample Configuration 1: Range-pole
with HiPer Lite Receiver
Before initializing or localizing a GPS+ system, there must be an
equipment configuration file defined in Pocket-3D. The following
procedure is an example of a HiPer Lite receiver configuration.
1. Press SetupEquipment. The Machine files dialog box
displays.
2. On the Machine files dialog box, press New to create (or Edit to
change a selected file) an equipment configuration (
Figure 2-19
on page 2-14).
3. On the Configuration name dialog box, set the following
equipment parameters, and press Next (
Figure 2-19 on 
page 2-14):
NOTICE
Incorrect measurements or typographical errors will
have a direct affect on grading accuracy.
