Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-69
950 103 IMAGE_PARAM_THROUGH1 Image Quality
Parameter
Through Setting
1
0bit0 0: ENL
Conversion
bit1 1: RGB 3x9 Filter
bit2 2:
Enlarge/Reduce
bit3 3: 3x9 Color
Conversion
bit4 4: Background
Suppression
bit5 5: NSP
bit6 6: NSP
(Saturation
Conversion Factor)
bit7 7: Color
Adjustment (Linear
Conversion)
950 104 IMAGE_PARAM_THROUGH2 Image Quality
Parameter
Through Setting
2
0-255 0 Continued from
"Image Quality
Parameter Through
Setting 1"
bit0 8: Color
Adjustment (L*
INLUT)
bit1 9: 4-Color DLUT
Color Conversion
bit2 10: 3-Color DLUT
Color Conversion
bit3 11: JPEG
Compression
bit4 12: K 5x5 Filter
bit5 13: Resolution
Conversion
bit6 14: Delete Border
bit7 15: TRC
950 105 IMAGE_PARAM_THROUGH3 Image Quality
Parameter
Through Setting
3
0-255 0 Continued from
"Image Quality
Parameter Through
Setting 1, 2"
bit7 16 - 23: Reserve
Parameter List
Chain Link Parameter Name Range
Fac’y
Def’lt
Note

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
