Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-107
094 911 IOT Belt Unit Life
Over
Detect Belt Unit Life
Over
Replace
Transfer Unit
Has Trans Unit
been replaced?
(Press
OK to counter reset.)
Replace the
Transfer Belt
Unit.
116 210 USB Host Error Fatal error of USB Host
driver
USB Host Error
Power Off/On
Error 116-210
Power Off/On
Replace the
IP Board.
116 312 Encryption Key
Error
Encryption key
mismatch
HDD Error
Power Off/On
Error 116-312
Power Off/On
Replace the
IP Board.
116 313 Encryption
Setting Error
Encryption setting
mismatch
HDD Error
Power Off/On
Error 116-313
Power Off/On
Replace the
IP Board.
116 314 On Board
Network MAC
Address
Checksum Error
MAC Addr. Error
Power Off/On
Error 116-314
Power Off/On
Replace the
IP Board.
116 315 ESS On Board
RAM W/R Check
Fail
Detected by On Board
RAM W/R Check at the
time of initialization.
RAM Error
Power Off/On
Error 116-315
Power Off/On
Replace the
IP Board.
116 316 ESS DIMM Slot
RAM W/R Check
Fail
Detected by DIMM Slot
RAM W/R Check at the
time of initialization.
DIMM RAM Error
Reseat Memory
Error 116-316
Power Off/On
Replace the
IP Board.
116 317 ESS ROM
Check(Main) Fail
Main Program ROM
checksum error
Controller Error
Power Off/On
Error 116-317
Power Off/On
Replace the
IP Board.
116 320 ESS DIMM Slot
RAM Error
Occurs when unusable
DIMM is inserted in
DIMM slot in
initialization processing
at power-on.
DIMM Error
Reseat Memory
Error 116-320
Power Off/On
Replace the
IP Board.
Phaser 6600 Error Code List
