Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-189
010-317 IOT Fuser Detached
010-351 IOT Fuser Life Over
010-397 IOT Fuser Failure
042-700 IOT Over Heat Stop
Step Check Yes No
Possible causative parts:
• Fuser Assembly (PL7.1.1)
• Heater Harness Assembly (PL7.1.5)
• Top Harness Assembly (PL18.2.5)
• LVPS (PL18.1.34)
• MCU Board (PL18.1.13)
1 Check the Fuser Assembly installation
Are the Fuser Assembly, and the drawer connector (DP/J281)
of the printer installed properly (without a bent pin, or any
foreign or burnt objects, etc.)?
Go to step 2. Reinstall the
Fuser Assembly.
2 Check the Fuser Assembly connection
Check the connection between the Fuser Assembly and the
MCU Board, and the connection between the Fuser Assembly
and the LVPS.
Are P/J281, P/J28, and P/J47 connected securely?
Go to step 3. Connect P/J281,
P/J28, and P/J47
securely.
3 Check the connections between LVPS and the MCU Board
Check the connection between the LVPS and the MCU Board.
Are P/J508 and P/J29 connected securely?
Go to step 4. Connect P/J508
and P/J29
securely.
4 Check the Heater Harness Assembly continuity.
Is each cable of P/J281<=>P/J47 continuous?
Go to step 5. Replace the
Heater Harness
Assembly.
5 Check the Top Harness Assembly continuity.
Is each cable of P/J281<=>P/J28 continuous?
Go to step 6. Replace the Top
Harness
Assembly.
6 Check the power to the Fuser Assembly (+5 VDC)
Check if the voltage between the MCU Board ground and the
P/J28-2 pin is about +5 VDC.
Go to step 7. Refer to “+5 VDC
Power FIP” on
page 2-223.
7 Check after replacing the Fuser Assembly
Replace the Fuser Assembly.
Does the error still occur?
Go to step 8. Finished.
8 Check after replacing the LVPS
Replace the LVPS.
Does the error still occur?
Replace the MCU
Board.
Finished.

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
