Xerox WorkCentre 6605

Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-194
8 Check the 550 Option Drive Assembly operation
Execute Digital Output diagnostic test 071-014, and check
the 550 Option Drive Assembly rotation.
Does the 550 Option Drive Assembly function normally?
Replace the MCU
Board.
Refer to
page 2-218.
Step Check Yes No
