Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-204
091-920 DRUM Y CRUM Data Broken Fail
091-960 IOT X CRUM ID Error (Y DRUM)
091-922 DRUM M CRUM Data Broken Fail
091-961 IOT X CRUM ID Error (M DRUM)
091-923 DRUM C CRUM Data Broken Fail
091-962 IOT X CRUM ID Error (C DRUM)
Step Check Yes No
Possible causative parts:
• Yellow Imaging Unit (PL8.1.2)
1 Check the Imaging Unit installation
Is an Imaging Unit other than a Yellow Imaging Unit
installed?
Or, is the installed Imaging Unit for another printer?
Install the right
Yellow Imaging
Unit.
Reinstall the
Yellow Imaging
Unit.
Step Check Yes No
Possible causative parts:
• Magenta Imaging Unit (PL8.1.3)
1 Check the Imaging Unit installation
Is an Imaging Unit other than a Magenta Imaging Unit
installed?
Or, is the installed Imaging Unit for another printer?
Install the right
Magenta
Imaging Unit.
Reinstall the
Magenta
Imaging Unit.
Step Check Yes No
Possible causative parts:
• Cyan Imaging Unit (PL8.1.3)
1 Check the Imaging Unit installation
Is an Imaging Unit other than a Cyan Imaging Unit
installed?
Or, is the installed Imaging Unit for another printer?
Install the right
Cyan Imaging
Unit.
Reinstall the
Cyan Imaging
Unit.

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
