Maintenance
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
6-9
5. Place the removed waste cartridge on a level surface.
CAUTION: To avoid toner spills or malfunction, do not lay the waste cartridge on its side.
6. Remove the cleaning rod from inside the printer.
7. Insert the cleaning rod into one of the four cleaning holes until it clicks, then pull it out. Repeat this
two more times. Repeat this step for the other three colors.
