Xerox WorkCentre 6605

Wiring
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
7-3
38 J-163 Connects MCU Board and Exit Clutch2 (Exit Drive Assembly)
39 J-164 Connects MCU Board and Regi Harness Assembly
40 B-158 Connects LVPS and Top Harness Assembly
40 J-163 Connects MCU Board and Exit Clutch1 [Exit Drive Assembly]
41 B-157 Connects LVPS and Rear Interlock Switch
42 B-157 Connects LVPS and Front Interlock Switch
43 B-158 Connects LVPS and Top Harness Assembly
47 H-157 Connects LVPS and Heater Harness Assembly
48 H-158 Connects LVPS and SW Harness Assembly
101 D-164 Connects IP Board and Main Harness Assembly
111 D-165 Connects IP Board and Laser Unit Video Harness Assembly
112 H-139 Connects Laser Unit and Laser Unit Video Harness Assembly
121 G-138 Connects Imaging Unit CRUM Y and X CRUM Harness Assembly
122 F-139 Connects Imaging Unit CRUM M and X CRUM Harness Assembly
123 F-139 Connects Imaging Unit CRUM C and X CRUM Harness Assembly
124 E-140 Connects Imaging Unit CRUM K and X CRUM Harness Assembly
131 I-152 Connects CTD Sensor Assembly and Regi Harness Assembly
132 G-152 Connects inside CTD Sensor Assembly
141 F-108 Connects Dispenser Motor (YM) and Upper Dispenser Motor Assembly
144 G-109 Connects Dispenser Motor (CK) Motor and Upper Dispenser Motor Assembly
145 H-109 Connects Front Cover Sensor and Upper Dispenser Motor Assembly
151 F-122 Connects Sensor Harness Assembly and Sensor Harness Assembly
154 F-122 Connects Full Stack Sensor and Exit Sensor Harness Assembly
155 E-122 Connects Exit Sensor and Exit Sensor 2 Harness Assembly
171 E-108 Connects Main Motor and Drive Harness Assembly
172 E-110 Connects Paper Transport Motor and Drive Harness Assembly
181 I-171 Connects Development HVPS Board and MCU-HVPS Flat Flex Connector (FFC)
182 H-173 Connects Development HVPS Board and HVPS Harness Assembly
191 F-136 Connects Toner CRUM Y and Top Harness Assembly
192 F-137 Connects Toner CRUM M and Top Harness Assembly
193 G-137 Connects Toner CRUM C and Top Harness Assembly
P/J Coordiates Remarks
