Xerox WorkCentre 6605 Service Manual

General Information
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
1-82
Transmission Time
Transmission time (T
p
) of image data in G3 mode is as follows.
Resolution conversion is not performed during transmission, and density is normal.
Specified value condition: ECM (No data error)
Protocol Control Time
When no data error occurs, protocol control time (T
m
, T
n
, T
u
) is as follows.
V.17, V.29, V.27ter
-V.34
In G3 mode, when a data error that exceeds the threshold occurs, Tn increases by about 6 seconds.
In ECM (Error Correction Mode), according to the number of resending operations performed for the
occurred data error, Tn increases by about Tn+1 seconds for each resending operation.
Chart
14.4Kbps
(MMR)
28.8Kbps
(MMR)
33.6Kbps
(JBIG)
a
a. Reference value
IIEEJ No.4 Super Fine 56 sec. or less 29 sec. or less 22 sec. or less
Fine 26 sec. or less 13 sec. or less 11 sec. or less
Standard 19 sec. or less 10 sec. or less 7 sec. or less
ITU-T No.1 Super Fine 30 sec. or less 15 sec. or less 12 sec. or less
Fine 15 sec. or less 8 sec. or less 6 sec. or less
Standard 11 sec. or less 6 sec. or less 4 sec. or less
FX English Sales Text Standard 7 sec. or less 4 sec. or less 2 sec. or less
FX Japanese Sales Text Standard 9 sec. or less 5 sec. or less 4 sec. or less
IIEEJ No.1 Standard 75 sec. or less 38 sec. or less 20 sec. or less
Mode
Before
messages: Tm
Between
messages: Tn
After
messages: Tu
Total
Standard protocol 16.4 sec. or less 3.2 sec. or less 4.4 sec. or less 24.0 sec. or less
Mode
Before
messages: Tm
Between
messages: Tn
After
messages: Tu
Total
Standard protocol 9.9 sec. or less 1.0 sec. or less 0.9 sec. or less 11.8 sec. or less

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
