248 Chapter 14
Using Printer
Printing onto a Printer Directly Connected to Agilent 4294A
Printing onto a Printer Directly Connected to Agilent 4294A
The Agilent 4294A provides direct connection to a printer, allowing you to print a
hardcopy of the LCD screen.
The printer can be connected to the printer parallel port on the rear panel of the 4294A. See
Operation Manual for detailed information on the connection and supported printers.
Setting images to be printed
Besides traces, the following items can be displayed on the LCD for printing.
Use the command below to restore the normal screen display from the screen with the
above items.
• “RESD” on page 411
Items Command
Sweep and measurement parameters for all
measurement points
“LISV” on page 341
Current parameter values for setting of the instrument “OPEP” on page 365
Setting values set for a user-defined calibration kit “CALS” on page 275
Setting values for a fixture compensation standard “COMS” on page 281
List sweep table “DISL” on page 299
Limit line table “DISLLIST” on page 299
To Next Page
