296 Chapter 16
GPIB Command Reference
DEFEC{R1|C1|L1|C0}
DEFEC{R1|C1|L1|C0}
Syntax DEFECR1 <numeric>[OHM]
DEFEC{C1|C0} <numeric>[F]
DEFECL1 <numeric>[H]
DEFEC{R1|C1|L1|C0}?
Description Defines an R1/C1/L1/C0 equivalent circuit parameter. The “DEFECR1” command defines
R1; the “DEFECC1” command, C1; the “DEFECL1” command, L1; the “DEFECC0”
command, C0, respectively. For equivalent circuit parameters, refer to
“Equivalent circuit
analysis” on page 100.
Parameters
If the specified parameter is out of the allowable setting range, the minimum value (if the
lower limit of the range is not reached) or the maximum value (if the upper limit of the
range is exceeded) is set.
Query response {numeric}<newline><^END>
Corresponding
key
[Display] - more 1/2 - EQUIV CKT - DEFINE PARAMETERS - {R1 | C1 | L1 | C0}
<numeric>
Description Value of the equivalent circuit parameter
Range -1E18 to 1E18
Initial value 0
Unit Ω (for the “DEFECR1” command)
F (for the “DEFECC1” command and the “DEFECC0” command)
H (for the “DEFECL1” command)
Resolution 1E-18
