Agilent Technologies 4294A Programming Manual

438 Chapter 16
GPIB Command Reference
SMKR{1-7}
SMKR{1-7}
Syntax SMKR{1|2|3|4|5|6|7} {ON|OFF|1|0}
SMKR{1|2|3|4|5|6|7}?
Description For the active trace (set with the “TRAC” command on page 457), turns on/off a sub
marker (marker number 1 to 7). In the coupled marker mode (set with the “MKRCOUP”
command on page 352), the setting is applied to both the A and B traces regardless of the
active trace setting. The sub marker set to on with this command is displayed at the same
position as the marker. If the marker function is off, executing this command causes an
error and the command is ignored.
Parameters
Query response {ON|OFF|1|0}<newline><^END>
Corresponding
key
[Marker] - SUB MKR - {1: OFF | 2: OFF | 3: OFF | 4: OFF | 5: OFF | 6: OFF | 7: OFF}
[Marker] - CREAR SUB MKR - {1: OFF | 2: OFF | 3: OFF | 4: OFF | 5: OFF | 6: OFF |
7: OFF}
SMKRAUV{1-7}?
Syntax SMKRAUV{1|2|3|4|5|6|7}?
Description For the active trace (set with the “TRAC” command on page 457), if the measurement
parameter is a vector value (for COMPLEX Z-Y), reads out the subsidiary readout of the
measurement parameter value at the sub marker position (marker number 1 to 7). (Query
only)
Query response {numeric}<newline><^END>
If the measurement parameter is a scalar value (for other than COMPLEX Z-Y), 0 is
always read out. If the measurement parameter is a vector value (for COMPLEX Z-Y), the
readout is as follows:
• If the polar chart format is selected, the phase is read out.
• If the complex plane format is selected, reactance (for trace A) or susceptance (for trace
B) is read out.
Corresponding
key
No front panel key is available to execute this function.
Description
ON or 1 Turns on a sub marker.
OFF or 0 (initial value) Turns off a sub marker.
