Chapter 16 297
GPIB Command Reference
DFLT
16. GPIB
Command Reference
( * , A - E )
DFLT
Syntax DFLT
Description Returns the settings related to printout to the initial states (refer to the table below). (No
query)
Corresponding
key
[Copy] - DEFAULT SETTING
DIN
Syntax DIN
DIN?
Description Sets the input/output direction of port D (24-bit I/O port) to input (preset state).
To change the input/output direction of port D to output, use the “DOUT” command on
page 307.
Query response {1|0}<newline><^END>
Corresponding
key
No front panel key is available to execute this function.
Setting item Setting command Initial state [unit]
Print resolution (DPI) “DPI” on page 308 75 [DPI]
Form feed “FORMFEED” on page 317 Enabled
Print orientation
(portrait/landscape)
“LANDSCAPE” on page 324 Portrait
Left margin “LMARG” on page 342 1 [inch]
Top margin “TMARG” on page 455 1 [inch]
Softkey label output “PRSOFT” on page 405 Disabled
Time and date output “COPT” on page 283 Disabled
Print color “PRIC” on page 405 Black and white
Description
1 Input is selected as the input/output direction of port D.
0 Output is selected as the input/output direction of port D.
