Chapter 16 355
GPIB Command Reference
MKRMON
16. GPIB
Command Reference
( F - N )
MKRMON
Syntax MKRMON {OFF|ACV|ACI|DCV|DCI}
MKRMON?
Description Enables/disables the display of the oscillator (OSC) level or dc bias level monitor value at
the marker position measurement point. If you try to specify monitoring an item whose
level monitor has been disabled in the oscillator level monitor function (set with the
“OMON” command on page 365) or dc bias level monitor function (set with the “BMON”
command on page 272), executing this command causes an error and the command is
ignored.
Parameters
Query response {OFF|ACV|ACI|DCV|DCI}<newline><^END>
Corresponding
key
[Utility] - LEVEL MON [ ] - {OFF | AC-V | AC-I | DC-V | DC-I}
MKRMOV
Syntax MKRMOV {CONT|DISC}
MKRMOV?
Description For the active trace (set with the “TRAC” command on page 457), switches between the
continuous marker mode (markers can be moved to between measurement points) and the
discrete marker mode (markers can be to measurement points only). In the coupled marker
mode (set with the
“MKRCOUP” command on page 352), regardless of the active trace
setting, this setting is applied to both the A and B traces. In the continuous marker mode,
the marker readout is an interpolated value derived from the data of the measurement
points on both sides.
Parameters
Query response {CONT|DISC}<newline><^END>
Corresponding
key
[Marker] - MKR [ ]
Description
OFF (initial value) Turns off the marker level monitor function.
ACV Specifies the monitor value display of the oscillator voltage level.
ACI Specifies the monitor value display of the oscillator current level.
DCV Specifies the monitor value display of the dc bias voltage level.
DCI Specifies the monitor value display of the dc bias current level.
Description
CONT (initial value) Specifies the continuous marker mode.
DISC Specifies the discrete marker mode.
