Agilent Technologies 4294A Programming Manual

328 Chapter 16
GPIB Command Reference
LIMITEST
LIMITEST
Syntax LIMITEST {ON|OFF|1|0}
LIMITEST?
Description For the active trace (set with the “TRAC” command on page 457), toggles on and off the
limit test function.
Parameters
Query response {1|0}<newline><^END>
Corresponding
key
[System] - LIMIT TEST - LIMIT TEST on OFF
LIMLSTAR
Syntax LIMLSTAR <numeric>[DEG|RAD|OHM|SIE|H|F|PCT]
LIMLSTAR?
Description In the creation/edit of the limit line table, sets the lower limit of the start point of each
segment (specified with the
“LIMSTAR” command on page 334). Use this command,
together with the “LIMUSTAR” command on page 337, when specifying the limits using
the upper limit and the lower limit.
If segment creation/edit has not been started, executing this command automatically starts
the edit of the edit target segment and then sets the lower limit of the start point.
If the creation/edit of the limit line table has not been started, executing this command
automatically starts table creation/edit, starts the edit of the edit target segment, and then
sets the lower limit of the start point.
Parameters
If the specified parameter is out of the allowable setting range, the minimum value (if the
lower limit of the range is not reached) or the maximum value (if the upper limit of the
range is exceeded) is set.
Query response {numeric}<newline><^END>
Corresponding
key
[System] - LIMIT TEST - EDIT LIMIT LINE - EDIT - LOWER LIMIT
Description
ON or 1 Turns on the limit test function.
OFF or 0 (initial value) Turns off the limit test function.
<numeric>
Description Lower limit of the segment start point
Range -1E9 to 1E9
Initial value When creating segment 1: 0
When creating an additional segment: Set value of the previous
segment
Unit Varies depending on the measurement parameter (refer to the
explanation of unit in
“SCAL” on page 423).
