298 Chapter 16
GPIB Command Reference
DISA
DISA
Syntax DISA {ALLI|HIHB|ALLB|BASS}
DISA?
Description Sets the allocation of the measurement result display screen and the HP Instrument BASIC
(IBASIC) screen on the LCD screen.
Parameters
Query response {ALLI|HIHB|ALLB|BASS}<newline><^END>
Corresponding
key
[Display] - more1/2 - ALLOCATION - {ALL INSTRUMENT | HALF INSTR HALF BASIC |
ALL BASIC | BASIC STATUS}
DISECIRC
Syntax DISECIRC {ON|OFF|1|0}
DISECIRC?
Description Toggles on and off the equivalent circuit model display.
Parameters
Query response {1|0}<newline><^END>
Corresponding
key
[Display] - more1/2 - EQUIV CKT - CIRCUIT on OFF
Description
ALLI (initial value) Uses the entire LCD screen as the measurement result display
screen.
HIHB Uses the upper half of the LCD screen as the measurement result
display screen and the lower half as the HP
IBASIC screen.
ALLB Uses the entire LCD screen as the HP IBASIC.
BASS Uses most of the LCD screen as the measurement result display
screen, showing the state of HP
IBASIC in three lines below the
measurement result display screen.
Description
ON or 1 Turns on the equivalent circuit model display.
OFF or 0 (initial value) Turns off the equivalent circuit model display.
