Agilent Technologies 4294A Programming Manual

Chapter 16 381
GPIB Command Reference
OUTPIACP?
16. GPIB
Command Reference
( O - R )
OUTPIACP?
Syntax OUTPIACP? <numeric 1>
Description When the oscillator level monitor function is set to on (set to ON with “OMON” command
on page 365), reads out the oscillator current level monitor value of the specified
measurement point. (Query only)
Parameters
If the specified parameter is out of the allowable setting range, the minimum value (if the
lower limit of the range is not reached) or the maximum value (if the upper limit of the
range is exceeded) is set.
Query response {numeric 2}<newline><^END>
If the oscillator level monitor function is set to off, the readout is invalid.
Corresponding
key
No front panel key is available to execute this function.
OUTPINPCIO?
Syntax OUTPINPCIO?
Description When input/output port C of the 24-bit I/O port is set to an input port (by the execution of
the
“CIN” command on page 278), 4-bit data is inputted into the 4294A through port C (C0
to C3) and the data is read out to the external controller. If port C is set to an output port,
executing this command causes an error and the command is ignored. This command has
the same function as the READIO(16,2) command of Instrument BASIC.
Query response {numeric}<newline><^END>
Corresponding
key
No front panel key is available to execute this function.
<numeric 1>
Description Number of the measurement point you want to read out (the
number assigned in order from the left edge assuming that the
number of the leftmost measurement point is 1)
Range 1 to the number of points
Resolution 1
{numeric 2}
Description Current monitor value of the oscillator level
{numeric}
Description Decimal value for the 4-bit binary data inputted from C0-C3,
assuming that C0 is LSB and C3 is MSB.
