388 Chapter 16
GPIB Command Reference
OUTPMSTA?
OUTPMSTA?
Syntax OUTPMSTA?
Description For the active trace (set with the “TRAC” command on page 457), calculates the statistics
(mean value, standard deviation, and difference value between the maximum value and the
minimum value) within the search range on the trace selected as the marker use target trace
(set with the
“MKRO” command on page 356), and reads out the result. (Query only)
Query response {numeric 1},{numeric 2},{numeric 3}<newline><^END>
Corresponding
key
No front panel key is available to execute this function.
OUTPMTRC?
Syntax OUTPMTRC?
Description Reads out the values of all measurement points in the memory trace array (refer to
“Internal data arrays” on page 81). (Query only)
Query response {numeric 1},{numeric 2},..,{numeric NOP×2-1},{numeric NOP×2}<newline><^END>
Reads out the readout and subsidiary readout of the measurement parameter value of each
measurement point as shown below. Where, NOP is the number of points, and n is an
integer between 1 and NOP.
{numeric n×2-1}: Readout of the n-th measurement point. If the measurement parameter
is a scalar value (for other than COMPLEX Z-Y), the measurement
parameter value is read out. If the measurement parameter is a vector
value (for COMPLEX Z-Y), resistance (for trace A) or conductance
(for trace B) is read out.
{numeric n×2}: Subsidiary readout of the n-th measurement point. If the measurement
parameter is a scalar value (for other than COMPLEX Z-Y), 0 is
always read out. If the measurement parameter is a vector value (for
COMPLEX Z-Y), reactance (for trace A) or susceptance (for trace B)
is read out.
Corresponding
key
No front panel key is available to execute this function.
{numeric 1} {numeric 2} {numeric 3}
Description Mean value Standard deviation Difference value between the
maximum value and the
minimum value
