Agilent Technologies 4294A Programming Manual

322 Chapter 16
GPIB Command Reference
INPUDTRC
INPUDTRC
Syntax INPUDTRC <numeric 1>,<numeric 2>,..,<numeric NOP×2-1>,<numeric NOP×2>
Description Enters a data trace array (refer to “Internal data arrays” on page 81). A mismatch, between
the number-of-points setting at the execution of the command and the number of entered
parameters, causes an error and the command is ignored. (No query)
Parameters
Regardless of the measurement parameter setting, 2 parameters are required for each
measurement point (total of NOP×2 parameters). Where, NOP is the number of points, and
n is an integer between 1 and NOP.
Corresponding
key
No front panel key is available to execute this function.
INTE
Syntax INTE <numeric>[PCT]
INTE?
Description Sets the brightness of the LCD screen.
Parameters
If the specified parameter is out of the allowable setting range, the minimum value (if the
lower limit of the range is not reached) or the maximum value (if the upper limit of the
range is exceeded) is set.
Query response {numeric}<newline><^END>
Corresponding
key
[Display] - more 1/2 - MODIFY COLOR - INTENSITY
Description
<numeric n×2-1> The measurement parameter value of the n-th measurement point. If
the measurement parameter is a vector value (COMPLEX Z-Y), the
real part of the measurement parameter value (complex number).
<numeric n×2> If the measurement parameter is a vector value (COMPLEX Z-Y),
the imaginary part of the measurement parameter value (complex
number) of the n-th measurement point. If the measurement
parameter is a scalar value, the value is always 0.
<numeric>
Description Percentage of the brightest status
Range 0 to 100
Initial value 100
Unit % (percentage)
Resolution 1
