Agilent Technologies 4294A Programming Manual

348 Chapter 16
GPIB Command Reference
MEAS
MEAS
Syntax MEAS {IMPH|IRIM|LSR|LSQ|CSR|CSQ|CSD|AMPH|ARIM|LPG|LPQ|CPG|CPQ|CPD|COMP
|IMLS|IMCS|IMLP|IMCP|IMRS|IMQ|IMD|LPR|CPR}
MEAS?
Description Selects impedance measurement parameters as a pair for trace A and trace B. Selecting
COMP specifies the vector measurement; selecting others, the scalar measurement. There
are functional differences between the vector measurement and the scalar measurement
including available display formats and trace operations.
Parameters
For details on each measurement parameter, refer to “Setting Measurement Parameters” on
page 36.
Query response {IMPH|IRIM|LSR|LSQ|CSR|CSQ|CSD|AMPH|ARIM|LPG|LPQ|CPG|CPQ|CPD|COMP|I
MLS|IMCS|IMLP|IMCP|IMRS|IMQ|IMD|LPR|CPR}<newline><^END>
Set measurement parameters
Trace A Trace B
IMPH (initial value) |Z| θ
IRIM R X
LSR Ls Rs
LSQ Ls Q
CSR Cs Rs
CSQ Cs Q
CSD Cs D
AMPH |Y| θ
ARIM G B
LPG Lp G
LPQ Lp Q
CPG Cp G
CPQ Cp Q
CPD Cp D
COMP Z Y
IMLS |Z| Ls
IMCS |Z| Cs
IMLP |Z| Lp
IMCP |Z| Cp
IMRS |Z| Rs
IMQ |Z| Q
IMD |Z| D
LPR Lp Rp
CPR Cp Rp
