368 Chapter 16
GPIB Command Reference
OUT2{H|L}
OUT2{H|L}
Syntax OUT2{H|L}
Description Sets the OUTPUT2 of the 24-bit I/O port to HIGH (or LOW). (No query)
Corresponding
key
No front panel key is available to execute this function.
OUT2ENV{H|L}
Syntax OUT2ENV{H|L}
OUT2ENV{H|L}?
Description Makes the setting so that OUTPUT2 goes to HIGH (or LOW) when a pulse is inputted to
INPUT1 of the 24-bit I/O port.
Corresponding
key
No front panel key is available to execute this function.
OUT8IO
Syntax OUT8IO <numeric>
Description Outputs data to OUT0 to OUT7 of the 8-bit I/O port. Data is outputted as 8-bit binary,
assuming that OUT0 is LSB and OUT7 is MSB. This command has the same function as
the WRITEIO 15,0 command of Instrument BASIC. (Query only)
Parameters
If the specified parameter is out of the allowable setting range, the minimum value (if the
lower limit of the range is not reached) or the maximum value (if the upper limit of the
range is exceeded) is set.
Corresponding
key
No front panel key is available to execute this function.
<numeric>
Description Output data
Range 0 to 255
Resolution 1
