Agilent Technologies 4294A Programming Manual

362 Chapter 16
GPIB Command Reference
NEGL
NEGL
Syntax NEGL
NEGL?
Description Sets the input/output signals of the 24-bit I/O port (data and test PASS/FAIL output) to
negative logic (preset state). To specify positive logic, use the
“POSL” command on page
403.
Query response {1|0}<newline><^END>
Corresponding
key
No front panel key is available to execute this function.
NEXNPK?
Syntax NEXNPK?
Description Within the waveform analysis range set with the “ANARANG” command on page 267,
searches for the minimum peak having a value more than the value of the negative peak
that has been detected at the last execution of this command or the
“NPEAK?” command
on page 364, and reads out the measurement parameter value and sweep parameter value of
the negative peak. If there are several applicable negative peaks, reads out the value of the
leftmost negative peak within the analysis range. If no peak exists, 0 is read out.
The negative peak searched for at the execution of this command satisfies the condition set
with the
“THRR” command on page 452. It is not related to the peak definition in the
marker search function. (Query only)
Query response {numeric 1},{numeric 2}<newline><^END>
Readouts are as follows:
{numeric 1}: Measurement parameter value of the detected negative peak
{numeric 2}: Sweep parameter value of the detected negative peak
Corresponding
key
No front panel key is available to execute this function.
Description
1 Negative logic is specified.
0 Negative logic is not specified. In other words, positive logic is specified.
