Agilent Technologies 4294A Programming Manual

Chapter 16 369
GPIB Command Reference
OUTAIO
16. GPIB
Command Reference
( O - R )
OUTAIO
Syntax OUTAIO <numeric>
Description Outputs data to output port A (A0 to A7) of the 24-bit I/O port. Data is outputted as 8-bit
binary, assuming that A0 is LSB and A7 is MSB. This command has the same function as
the WRITEIO 16,0 command of Instrument BASIC. (No query)
Parameters
If the specified parameter is out of the allowable setting range, the minimum value (if the
lower limit of the range is not reached) or the maximum value (if the upper limit of the
range is exceeded) is set.
Corresponding
key
No front panel key is available to execute this function.
OUTBIO
Syntax OUTBIO <numeric>
Description Outputs data to output port B (B0 to B7) of the 24-bit I/O port. Data is outputted as 8-bit
binary, assuming that B0 is LSB and B7 is MSB. This command has the same function as
the WRITEIO 16,1 command of Instrument BASIC. (No query)
Parameters
If the specified parameter is out of the allowable setting range, the minimum value (if the
lower limit of the range is not reached) or the maximum value (if the upper limit of the
range is exceeded) is set.
Corresponding
key
No front panel key is available to execute this function.
<numeric>
Description Output data
Range 0 to 255
Resolution 1
<numeric>
Description Output data
Range 0 to 255
Resolution 1
