Agilent Technologies 4294A Programming Manual

Chapter 16 325
GPIB Command Reference
LIMDSTAR
16. GPIB
Command Reference
( F - N )
LIMDSTAR
Syntax LIMDSTAR <numeric>[DEG|RAD|OHM|SIE|H|F|PCT]
LIMDSTAR?
Description In the creation/edit of the limit line table, sets the limit width (=upper value - central value)
of the start point of each segment (specified with the
“LIMSTAR” command on page 334).
Use this command, together with the “LIMVSTAR” command on page 339, when
specifying the limits using the central value and the width.
If segment creation/edit has not been started, executing this command automatically starts
the edit of the edit target segment and then sets the limit width of the start point.
If the creation/edit of the limit line table has not been started, executing this command
automatically starts table creation/edit, starts the edit of the edit target segment and then
sets the limit width of the start point.
Parameters
If the specified parameter is out of the allowable setting range, the minimum value (if the
lower limit of the range is not reached) or the maximum value (if the upper limit of the
range is exceeded) is set.
Query response {numeric}<newline><^END>
Corresponding
key
[System] - LIMIT TEST - EDIT LIMIT LINE - EDIT - DELTA LIMIT
<numeric>
Description Limit width of the segment start point
Range -1E9 to 1E9
Initial value When creating segment 1: 0
When creating an additional segment: Set value of the previous segment
Unit Varies depending on the measurement parameter (refer to the explanation
of unit in
“SCAL” on page 423).
