Agilent Technologies 4294A Programming Manual

46 Chapter 3
Setting Measurement Conditions
Setting the Limit Test Functions
Setting the Limit Test Functions
To turn on or off the limit test functions, use the command given below.
• “LIMITEST” on page 328
To use the limit test functions, you need to make a limit line table, which includes the limits
of sweep ranges (segments) defined by start points and endpoints. When beginning and
finishing a table, send the commands given below.
• “EDITLIML” on page 310
• “LIMEDONE” on page 326
NOTE With the “LIMEDONE” command not executed, the settings resulting from making,
editing, and deleting with the commands given below will not take effect, and the limit line
table is left as it was before execution of the “EDITLIML” command.
Making/editing a segment
To make a new segment, use the command given below. This command adds a segment
that is ready to be edited.
• “LIMSADD” on page 330
To set a segment's range (its start point and end point), use the commands given below.
• “LIMSTAR” on page 334
• “MKRLIMSTAR” on page 353
• “LIMSTOP” on page 336
• “MKRLIMSTOP” on page 353
To set a range for limiting start points, use the commands given below.
• “LIMUSTAR” on page 337
• “LIMLSTAR” on page 328
• “LIMVSTAR” on page 339
• “MKRLIMVSTAR” on page 354
• “LIMDSTAR” on page 325
To set a range for limiting endpoints, use the commands given below.
• “LIMUSTOP” on page 338
• “LIMLSTOP” on page 329
• “LIMVSTOP” on page 340
• “MKRLIMVSTOP” on page 354
• “LIMDSTOP” on page 326
