Agilent Technologies 4294A Programming Manual

442 Chapter 16
GPIB Command Reference
SPAN
SPAN
Syntax SPAN <numeric>[HZ|MHZ|V|A]
SPAN?
Description Sets the span value of the sweep range. To set the span value of each segment when
creating the list sweep table, also use this command.
Parameters
Note that, if you use this command to create a segment, the initial value is 0 regardless of
the sweep parameter.
If the specified parameter is out of the allowable setting range, the minimum value (if the
lower limit of the range is not reached) or the maximum value (if the upper limit of the
range is exceeded) is set.
Query response {numeric}<newline><^END>
Corresponding
key
[Span]
<numeric>
Description Span value
When the sweep
parameter is
frequency
Range 0 to 109.99996E6 (for linear sweep)
20 to 109.99996E6 (for log sweep)
Initial value 109.99996E6
Unit Hz
Resolution 1E-3
When the sweep
parameter is
OSC level (voltage)
Range 0 to 0.995
Initial value 0.995
Unit V (volt)
Resolution 1E-3
When the sweep
parameter is
OSC level (current)
Range 0 to 19.8E-3
Initial value 19.8E-3
Unit A (ampere)
Resolution 10E-6
When the sweep
parameter is
dc bias level (voltage)
Range 0 to 80
Initial value 0
Unit V (volt)
Resolution 1E-3
When the sweep
parameter is
dc bias level (current)
Range 0 to 200E-3
Initial value 0
Unit A (ampere)
Resolution 10E-6
