490 Appendix C
GPIB command table
GPIB command list sorted according to function
I/O port 8 bit I/O port Data output “OUT8IO” on page 368
Data input “INP8IO?” on page 319
24 bit I/O port Data output Port A “OUTAIO” on page 369
Port B “OUTBIO” on page 369
Port C “OUTCIO” on page 370
Port D “OUTDIO” on page 370
Port E “OUTEIO” on page 371
Port F “OUTFIO” on page 371
Port G “OUTGIO” on page 372
Port H “OUTHIO” on page 372
Data input Port C “OUTPINPCIO?” on page 381
Port D “OUTPINPDIO?” on page 382
Port E “OUTPINPEIO?” on page 382
Port C setting Set output port “COUT” on page 283
Set input port “CIN” on page 278
Port D setting Set output port “DOUT” on page 307
Set input port “DIN” on page 297
Check INPUT1 pulse input “INPT?” on page 319
OUTPUT1 setting High level / Low level “OUT1{H|L}” on page 367
Operation when INPUT1 detects
pulse input
“OUT1ENV{H|L}” on page 367
OUTPUT2 setting High level / Low level “OUT2{H|L}” on page 368
Operation when INPUT1 detects
pulse input
“OUT2ENV{H|L}” on page 368
Positive / Negative logic
selection
Positive logic “POSL” on page 403
Negative logic “NEGL” on page 362
Beep On/Off setting of the beep to notify the completion of operation “BEEPDONE” on page 270
On/Off setting of the beep when the limit test result is FAIL “BEEPFAIL” on page 271
On/Off setting of the beep when an error occurred or when an invalid key is pressed “BEEPWARN” on page 271
Clock Date display format setting “DMODE” on page 307
Date setting “SETCDATE” on page 436
Time setting “SETCTIME” on page 437
Key Disable front panel key and rotary knob “DSKEY” on page 308
Enable front panel key and rotary knob “ENKEY” on page 310
Send key code “KEY” on page 323
Show ON KEY LABELS “USKEY” on page 459
Others Wait for command operation completion “*WAI” on page 262
Read 1 when operation completes “*OPC?” on page 259
Set 1 to OPC bit when operation completes “*OPC” on page 259
Controller GPIB address setting “ADDRCONT” on page 263
Read product information “*IDN?” on page 259
Read option information “*OPT?” on page 260
Self test operation “*TST?” on page 261
Function Setting/Operation GPIB command
