Configuration
Request
This screen shows a protocol interpretation for the selected port (i.e. detailed
decoding information about K1 and K2 during the test). It also contains a set
of parameters that allow you configure the requests used in the test.
Select the configuration from below.
Ring: MS shared protection ring / BLSR (Bidirectional line switched ring)
Linear: Linear VC trail protection / UPSR (Unidirectional path switched
ring)
Short path, Long path: Type of substitute path for Ring protection.
1+1 architecture, 1:n architecture: Type of the architecture for Liner
protection.
Request
Use the drop-down menu to select the relevant request type (Forced
switch, Signal fail etc.).
Destination node / Source channel (K1)
Touch the field to set the channel number of the K1 byte (bits 5-8). Possible
values are 0 to 15.
Source node / Bridged channel (K2)
Touch the field to set the channel number of the K2 byte (bits 1-4). Possible
values are 0 to 15.
Apply
Touch the Apply button to apply the specified APS request to the
SDH/SONET transmitter.
5.8.3.4 Event Log
Touching the Event Log button in the navigation area displays the screen
providing the event log data. Refer to Event Log of SDH/SONET/PDH/DSn
BERT application.
5.8.3.5 Statistics
Touching the Statistics button in the navigation area displays the screen
providing the statistics data. Refer to Statistics of BERT for the operation.
5.9 BERT
