FEC Control
Use the drop-down menu to select whether or not to transmit FEC (Forward
Error Correction) data.
No FEC: FEC Decoding (Error Correction) is set OFF.
RS(255,239): FEC Error Correction is active based on RS(255,239) code
defined in ITU-T Rec. G.709.
TTI detection
Launches the TTI detection dialog box where you can select detection
method for SM, PM, and TCM1-6.
The dialog box is shown and described in the TTI detection section.
Auto, TP
Only displayed when the frame mapping is set to multiplexing. Touch the
Auto or TP # button and use the launched dialog box to set the number of
TP or TS. When Manual or Auto detect TS are selected, TP number can be
detect automatically, so "Auto" is shown on the button. Auto detect TP is
selected, TP number can be set directly. So "TP #" is shown on the button.
The dialog box is described in the TP/TS section below.
MSIM detection
Only displayed when the frame mapping is set to multiplexing. Touch the
MSIM detection button and use the launched dialog box to set the
detection method of MSIM.
The dialog box is shown and described in the MSIM Detection section.
Configure
Only displayed when the client signal is PRBS. Touch the Configure button
to launch a dialog box where you can select pattern type.
PRBS9 to PRBS31: Pseudo-random bit sequence. The number indicates
the bit length of sequence.
For example, bit length of PRBS9 is 2
9
-1=511.
User [32] bit, User [2048] bit: 32 bits or 2048 bits length pattern.
The field which shows bit length is enabled. Touch the field to launch the
dialog box to define the bit pattern. Refer to The User Pattern Editor.
TCM
Use the drop-down menu to select whether or not to enable measuring TCM
(Tandem Connection Monitoring) alarms and errors.
On: Enables measuring TCM alarms and errors.
Off: Disables measuring TCM alarms and errors.
7.1.2.3 TP/TS
Touching a TP or Auto button on the Ports Setup screen launches the
TP/TS dialog box. Note that the contents and layout of the dialog box
depends on which higher order type has been selected.
