BERT Options
Traffic Duration
10G WAN appears if Port on the Test Setup screen is set to '10 Gbps WAN'.
ETH
M.2100
10G WAN
G.826, G.826+G.829, M.2101.1(M.2100)
This option appears in the BERT application.
Count lost frames as pattern errors
Enabling this function means that if a frame is lost then all test pattern bits in
the frame are considered errored and will be included in the pattern error
counter.
Include addresses in frame filter on receiver
The receiver uses a filter to determine which frames should be counted in
the results. When this function is enabled then, by default, the receiver will
use the MAC and IP addresses of each incoming frame in addition to the
'filter key' used.
Only show BER Alarms when measuring
BER alarms in Interface status dialog box is enabled only when the
measurement is running. This function allows to avoid the BER alarms
occurrence when no data is input.
6.2.2.2 Generator
Touching the Generator button in the navigation area displays the following
screen.
The Follow button appears when the Port 2 settings can follow Port 1.
This screen contains the traffic-related parameters.
Allows you to set conditions concerning frames transmission. Choosing
Continuous will make a continual test sequence. Alternatively, the duration
can be set manually in either Seconds or Frames, coupled with a
specification of the number of seconds/frames in the adjacent field.
Automatically start the traffic generator when a test is started
In case of Continuous, you can select this check box to make the traffic
generator start synchronously with the test starting.
