Stream profile
Line load
6.2.2.3 Stream
Touching the Stream button in the navigation area displays the following
screen.
The Follow button appears when the Port 2 settings can follow Port 1.
This screen contains the parameters for specifying a profile and pattern for
each stream and for specifying which measurements are made.
Allows you to specify and configure a profile type for the currently selected
stream. Using the radio buttons, you can select the stream profile as either
Data, Video or Voice.
Encoding
Open the drop-down menu to select the relevant encoding type. The
available values depend on the selected profile type.
Number of channels
Specify the number of channels.
Using the radio buttons, you can select the line load profile as either
Constant or Ramp. If you select Ramp, you can touch the adjacent button
to display the Ramp Line Load Setup dialog box.
The dialog box contains the following settings:
