2.2 Mains Power Adapter
The Network Master can be powered from the supplied AC mains adapter.
CAUTION
Always use AC mains adapter delivered from Anritsu. Anritsu Part
No. G0309A.
2.2.1 Connecting Mains Power Adapter
To connect the mains power adapter to the Network Master, follow the
procedure below:
1. Insert the mains adapter's DC power plug into the socket connector
marked '18V DC'. The DC input connector is located on the right-hand
side of Network Master's connector panel.
2. Connect the AC plug of the mains adapter to the mains and switch on the
mains wall outlet. The power button will flash during booting. Then lit on
orange when charging.
2.3 Rechargeable Battery
