Link
Link partner
abilities
This is important information for identifying small frequency differences, which
may not be visible by showing the current bit rate difference.
The accumulated difference information is accumulated continuously. The
accumulation is reset when measurement is started or restarted.
LOS
Indicates whether LOS (Loss of Signal) of the transceiver is occured or not.
Link
Indicates whether Ethernet link is established or not.
Auto negotiation complete
Indicates whether Auto negotiation is completed or not.
Speed
10 Mbps, 100 Mbps, 1 Gbps or 10 Gbps is shown.
Duplex
FDX: Full Duplex, HDX: Half Duplex.
MDI/MDIX
MDI: Medium Dependent Interface, MDIX: Medium Dependent Interface
Crossover
Local clock
Master or Slave is shown.
When Electrical interface type is selected, the Link partner abilities is shown.
Pause capable
Indicates in green when the device is capable of flow control using Pause
request.
Asym. pause request
Indicates in green when the device is capable of asymmetric flow control
using Pause request.
Remote fault
Indicates in green when the device is sending the remote fault signal.
Speed/Duplex
Available speed and duplex are indicated in green.
6.1.3.3 Interface
Touching the middle summary box in the status area of the Ports Setup
screen displays the status shown below.
